My Amateur-Radio Equipment

I am member of the Radio-Amateur-Club OV C32 Ismaning

HF and more

Icom IC-756 Pro II

Type:

Amateur HF/VHF transceiver

Frequency range:

10-160 m + WARC/50-54 MHz

Mode:

AM/FM/SSB/CW/RTTY

RF Power output:

SSB/CW/FM/RTTY: 5-100/5-100 W
AM: 5-40/5-40 W

Sensitivity:

N/A

Selectivity:

N/A

Image rejection:

N/A

Voltage:

13.8 VDC

Current drain:

RX: Max 3.5 A
TX: Max 23 A

Impedance:

50 ohms, 2*SO-239

Dimensions (W*H*D):

340*111*285 mm

Weight:

9.6 Kg

Manufactured:

Japan, 2001-2004

Other:

32 bit IF-DSP. Built-in RTTY demodulator. Twin RX

Related documents:

User manual (1.9 MB)



Icom IC-7000

Type:

Amateur HF/VHF/UHF transceiver

Frequency range:

TX: 10-160 m + WARC / 6 m / 2 m / 70 cm
RX: 0.03-200 / 400-470 MHz

Mode:

AM/FM/SSB/CW/RTTY/PSK31

RF Power output:

FM/SSB/CW/RTTY: 2-100 / 2-100 / 2-50 / 2-35 W
AM: 1-40 / 1-40 / 2-20 / 2-14 W

Sensitivity:

AM (10 dB S/N)
0.5-1.8 MHz: 4 uV
1.8-29.9 MHz: 2 uV
50-54 MHz: 1 uV
144/440 MHz: 1 uV
FM (12 dB SINAD)
1.8-29.9 MHz: 0.5 uV
50-54 MHz: 0.25 uV
144/440 MHz: 0.18 uV
SSB/CW (10 dB S/N)
1.8-29.9 MHz: 0.15 uV
50-54 MHz: 0.12 uV
144/440 MHz: 0.11 uV

Selectivity:

AM (BW=6 KHz)
>6 KHz (-6 dB), <15 KHz (-60 dB)
FM (BW=15 KHz)
>12 KHz (-6 dB), <20 KHz (-60 dB)
SSB (BW=2.4 KHz)
>2.4 KHz (-6 dB), <3.9 KHz (-60 dB)
CW (BW=500 Hz)
>500 Hz (-6 dB), <900 Hz (-60 dB)
RTTY (BW=350 Hz)
>360 Hz (-6 dB), <650 Hz (-60 dB)

Image rejection:

HF: >70 dB
50/144/440 MHz: >65 dB

Voltage:

13.8 VDC

Current drain:

RX: 1.3-1.6 A
TX: Max 22 A

Impedance:

50 ohms, 2*SO-239

Dimensions (W*H*D):

167*58*180 mm

Weight:

2.3 Kg

Manufactured:

Japan, 2005-200x

Other:

2" (5 cm) TFT display. IF-DSP. 508 memories. Voice recorder. Detachable control head.
CTCSS/DTCS. Audio equalizer. Built-in voice synthesizer. CI-V. VHF channels NTSC-M
and PAL-B TV receiver on some versions.
New price 2008 in Sweden: 17500:- SEK

Related documents:

Manual (4.9 MB)



VHF/UHF and more

Yaesu FT-470R










Type:

Amateur VHF/UHF transceiver

Frequency range:

144-146 / 430-440 MHz (Europe)

Mode:

FM

RF Power output:

Hi: 5/5 W
Lo: 0,5/0,5 W

Sensitivity:

N/A

Selectivity:

N/A

Image rejection:

N/A

Voltage:

7.2-12 VDC

Current drain:

RX: 7-50 mA
TX: Max 1 A

Impedance:

50 ohms, BNC

Dimensions (W*H*D):



Weight:



Manufactured:

1989-1991

Other:

42 memories. Twin RX



Yaesu FT-290R

Type:

Amateur VHF transceiver

Frequency range:

144-146 MHz (Europe)
144-148 MHz (USA)

Mode:

FM/SSB/CW

RF Power output:

Hi: 2.5 W
Lo: 0.5 W

Sensitivity:

N/A

Selectivity:

N/A

Image rejection:

N/A

Voltage:

8.5-15.2 VDC

Current drain:

RX: 70 mA
TX: Max 800 mA

Impedance:

50 ohms, SO-239

Dimensions (W*H*D):

150*58*195 mm

Weight:

1.3 Kg (without batteries)

Manufactured:

Japan, 1981-1985

Other:

10 memories



Yaesu FT-736R

Type:

Amateur VHF/UHF transceiver

Frequency range:

144-146 / 430-440 MHz (Europe)

Mode:

FM/SSB/CW

RF Power output:

25/25 W

Sensitivity:

N/A

Selectivity:

N/A

Image rejection:

N/A

Voltage:

13.8 VDC or mains

Current drain:

RX: ? A
TX: Max ? A

Impedance:

50 ohms, 2*SO-239

Dimensions (W*H*D):

368*129*286 mm

Weight:

9 Kg

Manufactured:

1987-1993

Other:

6 m & 23 cm option

Scanner

AOR AR-8200 Mk3
















Type:

HF/VHF/UHF receiver/scanner

Frequency range:

0.1-3000 MHz

Mode:

AM/NAM/WAM/NFM/SFM/WFM/SSB/CW

Sensitivity:

AM (10 dB S/N)
0.53-2 MHz: 3.5 uV
2-30 MHz: 2.5 uV
30-470 MHz: 1.5 uV
NFM (12 dB SINAD)
30-470 MHz: 0.85 uV
470-1040 MHz: 0.9 uV
1040-2040 MHz: 9 uV
2040-3000 MHz: 25 uV
WFM (12 dB SINAD)
30-470 MHz: 1.5 uV

Selectivity:

SSB/NAM
3 KHz (-6 dB), 9 KHz (-60 dB)
AM/SFM
9 KHz (-6 dB), 20 KHz (-40 dB)
WAM/NFM
12 KHz (-6 dB), 25 KHz (-40 dB)
WFM
150 HKz (-3 dB), 360 KHz (-20 dB)

Voltage:

4.8-6 VDC (4*R6/AA) or 12 VDC external

Current drain:

25-190 mA

Impedance:

50 ohms, BNC

Dimensions (W*H*D):

61*143*39 mm

Weight:

217 gr (without batteries and antenna)

Other:

1000 channels in 20 banks. TXCO. MW bar aerial.
RF preselection of mid VHF bands. Band scope.
Noise limiter. RS-232C. Optional slot cards include
EM8200 (extra memory), CT8200 (CTCSS),
RU8200 (20 sec recorder), TE8200 (tone eliminator),
VI8200 (voice inverter)





Microwave

24GHz Transverter

Information and picture will be added soon



All data from very informative site www.rigpix.com
